WWW.DBBP.COM is created in Leiden,the Netherlands
by Mark "Duckman" van der Kwaak
Website started in June 1996, and in November 2003
the company DBBP-Design was established.
KVK 28099353 | BTW NL001565474B57 | info@dbbp.com
The company specializes in Motorcycle Product Development,
for companies and private individuals, doing 3D laserscanning,
reverse engineering, product design, CAD work, photorealistic
rendering, prototyping and also has the connections to have your
design produced, whether it is sheetmetal, CNC or Casting. It
is almost impossible to visit a bikeshow and not see
parts designed by DBBP-Design
|
New product: Intake
manifolds for Weber DCOE and Dellorto DHLA, available in the webshop
|

Always adding new 2D and 3D CAD models
to the webshop
|
New product: Suspension
lowering studs for FLH/FX swingarm frames
available in the webshop
|
New product: Velocity
stacks, with or without stainless mesh, for Linkert M carbs, available
in the webshop
|
A
recently completed design was Cadbike
57, although this bike has not been built in real life (yet)
some of the parts such as handlebars, velocity stacks, brake
and clutchlevers are in production and available in the webshop
By the way we are
currently building Cadbike 56 and Cadbike 58 in real life
|
One of the many interesting projects in 2020 was to design and
produce a set of wheels for Ironpit, 26” front and 21”
rear, both CNC machined from solid blocks of 6061 aluminium
instead of from blanks.
|
These are not going on a bagger but on a Speedchopper! I also
did a matching set of brakediscs and a belt pulley, and am working
on more parts that will be going on the same bike.
|


Some of the
many designs I did for Motone
in 2019
After many years using my old Nextengine 3D laser scanner, for
2019 I have upgraded to a brandnew Einscan Pro 2x plus with engineering
pack (tripod and turntable) so if you need any reverse engineering
done you know where to find me!
|

A big project I did in 2018 was making reproductions of the
very rare 1942 Harley XA sparkplugcaps
I made about 30 and to my surprise sold them all, so I might
need to make another batch
|
Another new part now available under my own DBBP brand: Intake
manifolds for Weber IDF 40 & 44 carburetors, made with an
S&S E style flange on the engine side so they can be made to fit
on any Harley
Lost-wax cast aluminum, available at www.dbbpshop.com
only
|
A part I have been making under my own DBBP
brand,
the stainless steel Wavebars are now available
at
www.dbbpshop.com
and also at W&W
in polished or satin finish, with cast stainless
center
From CAD to
fullsize wooden prototype (thanks to Aad)
Triumph fueltank with internal fuelpump for
Motone,
now in full production!
I developed
and produced an electric start kit for Panheads
and Knuckleheads for German distributor W&W
New company
logo and new webshop!

I did the
CAD work and renderings for the next Le Mani Moto project

Some of the
many designs I did for Motone
over the last years

I developed
and produced cast-iron dogbone risers for W&W
I did the CAD for the KRGT1, which was built by L.A.Choprods for
Keanu Reeves and first shown to the public at the Las Vegas Bikefest
in 2011 |
I did
the CAD work and developed the frame with adjustable trail,
rake and seat height for Veon. Bike built by Krugger. This bike
won the 2010 AMD World Championship of Custombikebuilding. |
Did the CAD
work for frame, forks, tank and rear brakes
for this Paul Funk/Hogtech project
Designed an
oilcooler that fits in the place of a generator for people
using alternator/generator cases. Comissioned by W&W


The Belgian company Qtec-Engineering
had builds Harley based quads and trikes,
I made CAD drawings for them to use for obtaining TUV approval.
For the German company W&W we developed
a Weber carb kit for Twincams. Starting with CAD drawings, we
built prototypes, had the manifolds cast in aluminum, manufactured
the cable conversion and even wrote the user manual. More
info here and here
and here
and here |
Gard Hollinger at LACC asked me to design a smaller version of the Hildebrandt
oilfilter, that would be better suited for motorcycle use. This filter
is available at LACC and standard equipment on Saxon's MadJack.
History
Mark van der Kwaak has been involved in the Harley scene since 1985,
always designing and building his own stuff because buying it was too
easy and no fun.
Since 1994 Mark has worked in the Product Development department of
a factory that manufactures stainless steel pumps, where Mark designs
pump parts using advanced 3D CAD software (Pro/Engineer, later CREO
from PTC) . Before that he had various other jobs involving 3D CAD work.
Mark could not resist using these advanced tools for his bike passion
before and after work, and since 1996 he has been sharing his amazing
CAD-designs with the world on his website www.dbbp.com,
| The company that makes the CAD software Mark uses, was so impressed
with Mark's work that in exchange for the right to use his work
to promote their product they gave him a license so he could work
at home. A lot of motorcycle magazines
did features about his design work, Mark won a CAD design competition
and it became clear that the time was ripe to take the next step,
so on the 7th of November 2003 Mark started his own company: DBBP-Design. |
 |
 |
In February 2005 Mark was accepted as a member of the exclusive
Motorcycle
Design Association |
As an example of Mark's work,
he designed a range of parts with
Crime Scene Choppers that can be seen on quite a lot of show winning
bikes today.
|
The Company
After designing 58"Cad-bikes" Mark has an
impressive library of CAD parts that make it possible for him to make
a "mockup" visualisation of a design within a few hours. He
can advise builders on how to improve the handling of the motorcycle
before a single bolt has been assembled on the real bike. Or a single
penny spent...
Ofcourse he can also design a unique one-off Harley-based
bike for you, producing both production drawings and photo-realistic
images. Designing a whole bike can take anywhere between 30 and 300
hours, depending on how special you want it to be. Building a show-winning
bike this way might be cheaper than the old-fashioned way because all
the hand fabricated and CNC machined parts need to be made only once,
after all the changes were already made in the design stage and the
builder knows exactly what the finished bike will look like.
Mark is also available for smaller jobs, such as production
drawings of frames or other parts, trail calculations, and anything
else you can think of.
For larger jobs there is a waiting list, as Mark is
usually fully booked.
The Price
Mark charges €70 per hour for his design work (+
tax)
KVK 28099353 / BTW NL001565474B57
|
