1 January 2008
Inspired by Cole Foster's Moonrocket
I decided to try a full fairing on this bike.
10 July 2007
Changed size and colour of the Nitrous
bottle, added brake pedal and shifter pedal,
added rear brake calipers
3 July 2007
Added more detail to primary cover,
added clutch line and added a bottle
of Nitrous Oxide
26 June 2007
Replaced rear drumbrake with
a perimeter disc and a deep
dished sprocket, added a different
rearend and changed the colour.
19 June 2007
Added oillines and oil filler cap
22 May 2007
Moved the rear shock to a position
under the seat and started on oiltank.
8 May 2007
Added front perimeter brake and rear
fender. Added a wider red trimline to
the wheels. Changed the front shock
mount and started changing rear
suspension to match the style of the
1 May 2007
Lowered the whole bike by 1.5 inches
and changed the design of the wheels
17 April 2007
Added seat springs and changed the colour,
also much less chrome this time.
10 April 2007
Completed the pipes with some "Thunderbirds style" mufflers,
added headlight, completed RSD gearbox.
3 April 2007
Added carb and started on pipes
20 March 2007
Just playing around a bit with this one,
it is a bit weird but I like it... Added gascaps +
handlebars and started work on the seat.
13 March 2007
I added a set of fueltanks that follow the
angle of the ribs on the front cylinder, and
leave the front suspension fully exposed.
6 March 2007
I added a smooth rear drumbrake and the rear
chain, modified the front suspension too.
27 February 2007
I made a removable frame section, neccessary
to mount or remove the engine.
The front forks have been restyled to match the
20 February 2007
I worked on the lower frame, swingarm and forks
13 February 2007
I added something I have been wanting to
do for ages; a front suspension with the shock
mounted on the frame instead of on the forks.
This way the front end can be ultralight!
I added a modified version of the swingarm
that we built for Aad's bike (Cadbike 31), it
will be shortened a bit more next week.
6 February 2007
I designed some cast 10 spoke wheels,
kind of a mix of some classic styles I like.
Also I added the steering neck, fixed the trail
at 4 inches and the neck angle at 35 degrees.
30 January 2007
I started this project because I wanted to do a
model of the Twincam 88B and I had a crazy
idea for a frame that I want to try
